[ UDM-Pro ] รีวิว จำหน่าย ราคา Ubiquiti UniFi Dream Machine Pro All In one Security Router ที่รวมทุกอย่างไว้ในอุปกรณ์ตัวเดียว + UniFi SDN Controller
หมวดหมู่ : UniFi Cloud Gateways ,  Unifi Cloud Key ,  UniFi ,  Security Gateway ,
Share
Dream Machine Pro (UDM-Pro): ศูนย์กลางการจัดการเครือข่ายสำหรับองค์กร
Dream Machine Pro (UDM-Pro) คืออุปกรณ์ Gateway ระดับองค์กรที่ออกแบบมาสำหรับการติดตั้งในรูปแบบ rack-mount พร้อมทั้งการรองรับแอปพลิเคชั่น UniFi อย่างเต็มรูปแบบ มอบประสิทธิภาพสูงสุดถึง 10 Gbps และมาพร้อมกับสวิตช์ภายในเครื่อง
คุณสมบัติเด่น:
Unifi Network Application
คุณสามารถบริหารจัดการระบบ Unifi และอุปกรณ์ทั้งหมดได้ง่ายๆ ด้วยการทำงานผ่าน Dashboard เพียงหน้าจอเดียว ไม่ว่าจะเป็น Unifi Network , Unifi Protect , Unifi Access , Unifi Talk
Unifi Network Controller
Unifi Protect Controller
Unifi Access Controller
Talk Controller
ควบคุมง่ายด้วย Mobile App
ในระบบ Unifi ก็มี Mobile App ให้คุณได้ใช้งานกันฟรีๆอีกด้วย
UDM-Pro | |
Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
Weight | 3.9 kg (8.6 lb) |
Enclosure material | Aluminium CNC, SGCC steel |
Mount material | SGCC steel |
Hardware | |
Processor | Quad-core ARM® Cortex®-A57 at 1.7 GHz |
System memory | 4 GB DDR4 |
On-board storage | 16 GB eMMC |
Management interface | Ethernet Bluetooth |
Networking interface | LAN: (8) GbE RJ45 ports (1) 10G SFP+ port WAN: (1) GbE RJ45 port (1) 10G SFP+ port |
IDS/IPS throughput | 3.5 Gbps* *Measured with iPerf3. |
Power method | (1) Universal AC input, 100—240V AC, 50/60 Hz (1) USP-RPS DC input |
Power supply | AC/DC, internal, 50W |
Supported voltage range | 100—240V AC |
Max. power consumption | 33W |
ESD/EMP protection | Air: ± 15kV, contact: ± 8kV |
LCM display | (1) 1.3" touchscreen |
Button | Factory reset |
Ambient operating temperature | -10° to 40° C (14° to 104° F) |
Ambient operating humidity | 5 to 95% noncondensing |
Certifications | CE, FCC, IC |
Gateway Features | |
Performance | Redundant WAN with failover and load balancing WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Additional internet failover with LTE Backup Internet quality and outage reporting |
Next-generation security | Application-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall |
Advanced networking | License-free SD-WAN WireGuard, L2TP and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport and Identity VPN Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IGMP proxy IPv6 ISP support |
LEDs | |
Ethernet | Link/activity Green: 1G Amber: 10/100M |
SFP+ | Link/activity White: 10G Green: 1G |
HDD | White: disk activity Amber: disk error |
RPS | Blue: ready |
