[ ER-6P ] รีวิว จำหน่าย ราคา Ubiquiti Edge Router ER-6P มี Port ทั้งสิ้น 6 Gigabit Router พร้อมกับ 1 Port SFP รองรับ Passive POE ได้จำนวน 5 Port
Share
Ubiquiti Networks ขอแนะนำผลิตภัณฑ์ในกลุ่ม Edgemax ในที่นี้นั้นก็คือ EdgeRouter รุ่น ER-6P ซึ่งเป็น Router ที่เปี่ยมไปด้วยประสิทธิภาพ และจุดเด่นเบื้องต้นของ ER-6P รุ่นนี้ก็คือ สามารถรองรับการ Forward ได้ 3.4 million packets per second ( Routing performance ) นอกจากนี้แล้ว ER-6P ยังมี Function PoE Out สำหรับจ่ายไฟออกไปเลี้ยงอุปกรณ์อื่นๆได้อีกด้วย
คุณสมบัติย่อของ Edge Router ER-6P
เข้าชมตารางเปรียบเทียบ EdgeRouter รุ่นต่างๆ ได้จากที่นี่
รองรับการทำ Load Balance
คุณสมบัติเด่นของ EdgeOS ( ระบบปฎิบัติการ )
Centralized Control ควบคุมจัดการทั้งหมดจากจุดศูนย์กลาง
คุณสามารถควบคุมบริหารจัดการอุปกรณ์ต่างๆ ได้ง่ายๆ ด้วย UISP
ควบคุมง่ายด้วย Mobile App
ในระบบ UISP ก็มีเป็น Mobile App ให้คุณได้ใช้งานกันฟรีๆ รองรับทั้ง Android และ IOS
ตารางคุณสมบัติจำเพาะรุ่น ER-6P | |
Dimensions | 229 x 136.5 x 31.1 mm (9.02 x 5.37 x 1.22") |
Weight | 730 g (1.61 lb) |
Max. Power Consumption | 16W (Excludes PoE Output) |
Power Method | External AC/DC Power Adapter, 60W (24V, 2.5A) (Included) |
Power Supply | External AC/DC Adapter |
Supported Voltage Range | 16 - 30VDC |
Button | Reset |
LEDs Data Ports SFP Data Port | - Speed/Link/Activity, PoE Link/Activity |
Interfaces Management - Networking | - (1) RJ45 Serial Port (6) Ethernet Ports (Default eth0) (5) 10/100/1000 RJ45 Ports with PoE (1) 1 Gbps SFP Port |
Layer 3 Forwarding Performance Packet Size: 64 Bytes Packet Size: 512 Bytes or Larger | - 3,400,000 pps 6 Gbps (Line Rate) |
Processor | 4-Core 1 GHz, MIPS64 |
System Memory | 1 GB DDR3 RAM |
On-Board Flash Storage | 4 GB eMMC, 8 MB SPI NOR |
Mounting | Wall, Rack* |
Operating Temperature | -10 to 45° C (14 to 113° F) |
Operating Humidity | 10 - 90% Noncondensing |
Certifications | CE, FCC, IC |
PoE with 24VDC Power Adapter | |
PoE Interfaces | (5) 24V Passive PoE Ports, 2-pair (4, 5+; 7, 8-) and 4-pair |
Passive PoE Max. Wattage Per Port | 24W (24V, 1A, 4-pair) 12W (24V, 0.5A, 2-pair) |
Voltage Range Passive PoE | 24V |
แนะแนวทาง
สมัครตัวแทนจำหน่ายสินค้า Ubiquiti Network กรอกฟอร์มที่เมนูของเราได้เลย | สอบถามราคาพิเศษ / ปรึกษา Solutions ติดต่อได้ที่ LiveChat
Edge OS Feature | |
Interface/Encapsulation | Ethernet 802.1q VLAN PPPoE GRE IP in IP Bridging Bonding (802.3ad) |
Addressing | Static IPv4/IPv6 Addressing DHCP/DHCPv6 |
Routing | Static Routes OSPF/OSPFv3 RIP/RIPng BGP (with IPv6 Support) IGMP Proxy |
Security | ACL-Based Firewall Zone-Based Firewall NAT |
VPN | IPSec Site-to-Site and Remote Access OpenVPN Site-to-Site and Remote Access PPTP Remote Access L2TP Remote Access PPTP Client |
Services | DHCP/DHCPv6 Server DHCP/DHCPv6 Relay Dynamic DNS DNS Forwarding VRRP RADIUS Client Web Caching PPPoE Server |
QoS | FIFO Stochastic Fairness Queueing Random Early Detection Token Bucket Filter Deficit Round Robin Hierarchical Token Bucket Ingress Policing |
Management | Web UI CLI (SSH, Telnet) SNMP NetFlow LLDP NTP UBNT Discovery Protocol Logging |
